1. The motor and pump are integrated into the water andoperate safely and reliably.
2. There are no special requirements forwell pipes and water pipes (ie: steel pipe wells can be used; under pressure permit,steel pipes,hoses, plastic pipes,etc.can be used as water pipes).
3. it is easy to install, use and maintain. It occupies a smallarea and does not require the construction of a pump room,
4. Simple structure and save raw materials. However, whetherthe submersible electric pumps are used in appropriate conditions is directly related to their service life.

Application

• For water supply from wells or reservoirs.
• For domestic use,for civil and industrial applications.
• For garden use and irrigation.

Operating Conditions

• Maximum fluid temperature up to+40℃
• Maximum sand content:0.25%
• Maximumimmersion:70m
• Minimum well diameter:3′

Usage Precautions:

• SDM series deep well pump equip with oil filled motor, do not addany water into motor.
• No warranty if install in the water with too many sediment.
• Please confirm with us in advance about the length cable size
• Non-return valve must be installed

Motor and Pump

• Three-phase:380v-415V/50Hz
• Single-phase:220V-240V/50Hz
• Pumps are designed by casing stressed

Options on Request

• Equip digital auto-control box
• Special mechanical seal
• Other voltages or frequency 60 Hz
